Product Summary

The SKKE 301F12 is a Fast Diode Module. The applications of the SKKE 301F12 include self-commutated inverters, DC choppers, AC motor speed control, Inductive heating, Uninterruptible power supplies, Electronic welders, General power switching applications.

Parametrics

SKKE 301F12 absolute maximum ratings: (1)IFAV: 220A; (2)IFSM: 4000A; (3)I2T: 80000A2S; (4)VF: max.2,2V; (5)V(to): max.1,2V; (6)rT, Tvj=25℃: max.2,75V; (7)IRD, Tvj=150℃: max.80mA.

Features

SKKE 301F12 features: (1)CAL (control axial lifetime) technology patent NO.DE 43 10 44; (2)Heat transfer through ceramic isolated metal baseplate; (3)Very short recovery times; (4)Very soft recovery over the whole current range; (5)Low switching losses; (6)UL recognized, file no. E 63532.

Diagrams

SKKE 301F12 block diagram
