Product Summary

The SKIIP31NAB065T12 is a 3-phase bridge rectifier+braking chopper and 3-phase bridge inverter.

Parametrics

SKIIP31NAB065T12 absolute maximum ratings: (1)VCES: 600V; (2)VGES: ±20V; (3)IC: 45/32A; (4)ICM: 90/64A; (5)IF=-IC: 57/38A; (6)IFN=-ICM: 114/76A.

Features

SKIIP31NAB065T12 features: (1)Case M3; (2)UL recognized file no.E63652; (3)Fast NPT IGBTs.

Diagrams

SKIIP31NAB065T12 block diagram
