Product Summary

The SKIIP20NAB121T45 is an intelligent Power module. The applications of the device include inverter and motor control applications.

Parametrics

SKIIP20NAB121T45 absolute maximum ratings: (1)IGBT-Inverter: VCES: 2.6V; (2)VCEO: 1.3V; (3)rCE: 1.1MΩ; (4)ICE: 144mA; (5)Eon +Eoff: 635mJ.

Features

SKIIP20NAB121T45 features: (1)SKiip technology inside; (2)SPT (soft punch trough) IGBTs; (3)CAL diode technology; (4)Integrated current sensor; (5)Integrated temperature sensor; (6)Integrated heat sink; (7)IEC 60721-3-3 (humidity) class 3K3/IE32; (8)IEC 60068-1(climate) 40/125/56; (9)UL recognized file no.E65532.

Diagrams

SKIIP20NAB121T45 block diagram
