Product Summary

The FZ1200R12KF5 is an IGBT Module.

Parametrics

FZ1200R12KF5 absolute maximum ratings: (1)VCES: 1200V; (2)IC: 1200V; (3)ICRM: 2400A; (4)Ptot: 7800W; (5)VGE: 20V; (6)VEG: 20V; (7)tvj max: 150℃; (8)tvj op: -40 to 150℃; (9)tstg: -40 to 125℃.

Features

FZ1200R12KF5 features: (1)Power module; (2)3-phase full-bridge; (3)Including fast free-wheel diodes; (4)Package with insulated metal base plate; (5)E3226: long terminals, limited current per terminal; (6)Half-bridge /Chopper; (7)Package outlines /Circuit diagram: 2b, 2c; (8)Single switch with chopper diode; (9)Solderable Terminals.

Diagrams

FZ1200R12KF5 block diagram
