Product Summary

The FF600R12KE3 is an IGBT module.

Parametrics

FF600R12KE3 absolute maximum ratings: (1)collector emitter voltage, VCES: 600V; (2)DC collector current, ICnon: 150A; (3)repetitive peak collector current, ICRM: 300A; (4)total power dissipation, Ptot: 595W; (5)gate emitter peak voltage, VGES: ±20V; (6)DC forward current, IF: 150A; (7)repetitive peak forw current, IFRM: 300A.

Features

FF600R12KE3 features: (1)input capatitance, Cies: 6.5nF; (2)reverse transfer capacitance, Cres: 0.6nF; (3)collector emitter cut off current, ICES: 1mA; (4)gate emitter leakage current, IGES: 400nA.

Diagrams

FF600R12KE3 block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
FF600R12KE3
FF600R12KE3

Infineon Technologies

IGBT Modules 1200V 600A DUAL

Data Sheet

0-2: $384.02
2-3: $345.62
3-5: $307.22
5-10: $292.70
