CM450HA-5F

CM450HA-5F, IGBT module, 250V, 450A, 735W, MITSUBISHI

Rated 5 Rating 5 | reviews | Write a review

Price:: US $123.00~127.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 30 :	127.00 / Piece
32 ~ 43 :	125.00 / Piece
45 ~ 55 :	123.00 / Piece

PartNumber:: CM450HA-5F

Brand:: MITSUBISHI - MITSUBISHI | D/C: 98+

Availability:: Supply Ability: 300/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Mr. Jack's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-03-28

From Other Seller

Part Number:CM450HA-5F
US $123.00 - 127.00
Quantity:

piece

Product Summary

The CM450HA-5F is an IGBT module. It is designed for use in switching applications. Each module consists of one IGBT in a single configuration, with a reverse connected super-fast recovery free-wheel diode. All components and interconnects are isolated from the heat sinking baseplate, offering simplified system assembly and thermal management. The applications of the CM450HA-5F are UPS, Forklift.

Parametrics

CM450HA-5F absolute maximum ratings: (1)Junction Temperature: -40 to 150 ℃; (2)Storage Temperature: -40 to 125 ℃; (3)Collector-Emitter Voltage (G-E Short): 250 Volts; (4)Gate-Emitter Voltage (C-E Short): ±20 Volts; (5)Collector Current (TC = 25℃): 450 Amperes; (6)Peak Collector Current (Tj ≤ 150): 900Amperes; (7)Emitter Current (TC = 25℃): 450 Amperes; (8)Peak Emitter Current: 900 Amperes; (9)Maximum Collector Dissipation (TC = 25℃): 735 Watts; (10)Mounting Torque, M6 Main Terminal: 1.96 to 2.94 N · m; (11)Mounting Torque, M6 Mounting: 1.96 to 2.94 N · m; (12)Mounting Torque, M4 Terminal: 0.98 to 1.47 N · m; (13)Weight: 270 Grams; (14)Isolation Voltage (Main Terminal to Baseplate, AC 1 min.): 2500 Vrms.

Features

CM450HA-5F features: (1)Low Drive Power; (2)Low VCE(sat); (3)Discrete Super-Fast Recovery Free-Wheel Diodes; (4)High Frequency Operation; (5)Isolated Baseplate for Easy; (6)Heat Sinking.
