Product Summary
The CM100TU-24H is an IGBT Module. The applications of the CM100TU-24H include UPS, NC machine, AC-Drive control, Servo, Welders.
Parametrics
CM100TU-24H absolute maximum ratings: (1)Collector-emitter voltage, G-E Short, VCES: 1200V; (2)Gate-emitter voltage, C-E Short, VGES: ±20V; (3)Collector current, TC= 25℃, IC: 100A; (4)Collector current, pulse, ICM: 200A; (5)Emitter current, TC= 25℃, IE: 100A; (6)Emitter current, pulse, IEM: 200A; (7)Maximum collector dissipation, TC= 25℃, PC: 650W; (8)Junction temperature, TJ: -40 to +150℃; (9)Storage temperature, Tstg: -40 to +125℃; (10)Isolation voltage, Viso: 2500Vrms.
Features
CM100TU-24H features: (1)IC: 100A; (2)VCES: 1200V; (3)Insulated Type; (4)6-elements in a pack; (5)UL Recognized, Yellow Card No. E80276, File No. E80271.
Diagrams
