Product Summary

The BYV255V200 is a high efficiency fast recovery rectifier diode. It is suited for switchmode power supply and high frequency DC to DC converters. Packaged in ISOTOPTM this device is intended for use in low voltage, high frequency inverters, free wheeling and polarity protection applications.

Parametrics

BYV255V200 absolute maximum ratings: (1)IF(RMS), RMS forward current Per diode: 150 A; (2)IF(AV), Average forward current d = 0.5 Tc=110℃ Per diode: 100 A; (3)IFSM, Surge non repetitive forward current tp=10ms sinusoidal Per diode: 1600 A; (4)Tstg, Storage and junction temperature range: -40 to+150℃.

Features

BYV255V200 features: (1)suited for SMPS; (2)very low forward losses; (3)negligible switching losses; (4)high surge current capability; (5)high avalanche energy capability; (6)insulated: Insulating voltage = 2500 VRMS; Capacitance = 55 pF.

Diagrams

BYV255V200 block diagram
