Product Summary
The NA24W-K is a miniature relay.
Parametrics
NA24W-K absolute maximum ratings: (1)Nominal voltage: 24VDC; (2)Coil resistance (±10%): 2880Ω; (3)Must operate voltage: +18.0VDC; (4)Must release voltage: +2.4VDC; (5)Nominal power: 200mW.
Features
NA24W-K features: (1)Slim type relay for high density mounting; (2)Conforms to Bellcore specification and FCC Part 68: Dielectric strength 1,500 VAC between coil and contacts, Surge strength 2,500 V between coil and contacts (at 2 × 10 s surge wave); (3)Maximum switching capability - 4.2A, 700VAC; (4)UL, CSA recognized; (5)High sensitivity and low consumption power; (6)High reliability—bifurcated contacts; (7)DIL pitch terminals; (8)Plastic sealed type; (9)RoHS compliant since date code: 0437B8.
Diagrams
