Product Summary

The H7CN-YHNS is a kind of 1/16 DIN, Single Preset Counter with Four-Digit LED Display.

Parametrics

H7CN-YHNS specifications: (1)Classification: Single preset counter; (2)Mounting: Panel, track or surface; (3)External connections: 8-pin round sockets or 11-pin round sockets (-M types); (4)Output modes: Sustained output until reset; (5)Sensor power supply: Not provided; (6)Input signal: Count and reset; (7)Displays: 7-segment LED count value display, 8 mm (0.3 in) high characters, and LED indicators for count up and reset; (8)Digits: 4 digits.

Features

H7CN-YHNS features: (1)Choose from UP, DOWN and reversible counting; (2)Count speed up to 5 K counts per second; (3)Wide-range AC or DC supply voltages; (4)Contact and solid-state output models available; (5)Memory protectiocircuit available oAC models; (6)Easy-to-read 8 mm-high LED display; (7)Panel mounting adapter, sockets, and accessories available separately.

Diagrams

H7CN-YHNS circuit diagram
