G3NA-240B

G3NA-240B, Solid State Relay, 10 mA, 1.6 V, DIP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $41.00~61.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 10 :	61.00 / Piece
10 ~ 20 :	51.00 / Piece
20 ~ 30 :	41.00 / Piece

PartNumber:: G3NA-240B

Brand:: Omron Electronics LLC - OMRON | D/C:

Availability:: Supply Ability: 1000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Mr. Jack's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-08-23

From Other Seller

Part Number:G3NA-240B
US $41.00 - 61.00
Quantity:

piece

Product Summary

The G3NA-240B is a Solid State Relay.

Parametrics

G3NA-240B absolute maximum ratings: (1)Operate time, DC input: 1/2 of load power source cycle + 1 ms max; AC input: 1 1/2 of load power source cycle + 1 ms max; (2)Release time, DC input: 1/2 of load power source cycle + 1 ms max; AC input: 1 1/2 of load power source cycle + 1 ms max; (3)Output ON voltage drop: 1.6 V (RMS) max; (4)Leakage current: 5 mA max. at 100 VAC; 10 mA max. at 200 VAC; (5)Insulation resistance: 100 MΩ min at 500 VDC; (6)Dielectric strength: 2,500 VAC, 50/60 Hz for 1 minute; (7)Vibration Malfunction: 10 to 55 Hz, 1.5 mm double amplitude; (8)Shock Malfunction: 1,000 m/s2 (approx. 100G); (9)Ambient temperature Operating: -30 to 80℃; Storage: -30 to 100℃.

Features

G3NA-240B features: (1)All models feature the same compact dimensions to provide a uniform mounting pitch; (2)Built-in varistor effectively absorbs external surges; (3)Operation indicator (red LED) enables monitoring operation; (4)Protective cover for greater safety; (5)All models approved by UL/CSA; TUV approved models available; (6)Wide range of outputs: 5 to 40 A, up to 480 VAC/200 VDC; (7)Optional Y92B heat sinks allow relays to reach maximum rated loads; (8)25-amp version ideal for many industrial control applications.
