Product Summary
The G3F-202SN is a solid-state relay.
Parametrics
G3F-202SN absolute maximum ratings: (1)Operate time: 0.5 ms max.; (2)Release time: 2 ms max.; (3)Output ON voltage drop: 1.5 V max.; (4)Leakage current: 5 mA max. (at 50 VDC); (5)Insulation resistance: 100 MΩ min. (500 VDC); (6)Dielectric strength: 1,500 VAC, 50/60 Hz for 1 min; (7)Vibration resistance: 10 to 55 to10 Hz, 1.5-mm single amplitude; (8)Ambient temperature: Operating: -30°C to 100°C (with no icing or condensation); (9)Ambient humidity Operating: 45% to 85%.
Features
G3F-202SN features: (1)Sizes and terminal arrangements are the same as OMRON MY-series Power Relays. The same Sockets are also used; (2)DC-AC, DC-DC, AC-AC, AC-DC Types; (3)Operating indicator provided.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 G3F-202SN AC100/110 |
Omron Industrial |
Solid State Relays SOLID STATE RELAY |
Data Sheet |
|
|
||||||||||||
 |
G3F-202SN-VD AC100/110 |
|
RELAY SSR 200V 2A 100/110VAC |
Data Sheet |
|
|
||||||||||||
