Product Summary
The DSP1-DC24VDC is a miniature power relay in DS relay series. Applications are (1)Terminal devices of information processing equipment, such as printer, data recorder; (2)Office equipment (copier, facsimile); (3)Measuring instruments; (4)NC machines, temperature controllers and programmable logic controllers.
Parametrics
DSP1-DC24VDC absolute maximum ratings: (1)Breakdown voltage: 3,000 Vrms between terminals (Except for the portion between coil terminals); (2)Insulation resistance: 1,000 MW between terminals at 500 V; (3)Heat resistance: 150°C for 1 hour; (4)Max. continuous current ,1a: 8 A; 2a: 5 A.
Features
DSP1-DC24VDC features: (1)Power types added to DS relay series; (2)High switching capacity: 1a: 8 A 250 V AC / 1a1b, 2a: 5 A 250 V AC; (3)High sensitivity: 190 mW pick-up power; (4)High contact welding resistance; (5)Latching types available; (6)High breakdown voltage 3,000 Vrms between contacts and coil 1,000 Vrms between open contacts Meeting FCC Part 68; (7)Sealed types are standard.
