Product Summary

The ds2y-s-dc24v is a miniature relay. Applications of the ds2y-s-dc24v include: Telecommunication equipment, Office equipment, Computer peripherals, Security alarm systems and Medical equipment.

Parametrics

ds2y-s-dc24v absolute maximum ratings: (1) Max. switching power: 60W, 62.5VA; (2) Max. switching voltage: 220V DC,250V AC; (3) Max. switching current: 2A; (4) Max. carrying current: 3A; (5) Initial contact resistance, max.(By voltage drop 6 V DC 1 A) .

Features

ds2y-s-dc24v features: (1) 2 Form C contact; (2) High sensitivity-200 mW nominal operating power; (3) High breakdown voltage 1500V FCC surge between open contacts; (4) DIP-2C type matching 16 pin IC socket; (5) Sealed construction.

Diagrams

ds2y-s-dc24v circuit

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
DS2Y-S-DC24V
DS2Y-S-DC24V
Panasonic Electric Works
Low Signal Relays - PCB 2A 24VDC DPDT SEALED PCB
Data Sheet
0-1: $1.69
1-25: $1.68
25-50: $1.49
50-100: $1.27
DS2Y-S-DC24V-R
DS2Y-S-DC24V-R
Panasonic Electric Works
Low Signal Relays - PCB 24VDC 200MW DIP RELAY MINI
Data Sheet
Negotiable
DS2Y-S-DC24V-TB
DS2Y-S-DC24V-TB
Panasonic Electric Works
Low Signal Relays - PCB 24VDC 200MW DIP RELAY MINI
Data Sheet
0-1: $1.92
1-25: $1.76
25-50: $1.57
50-100: $1.33
