Product Summary
The CP1-12V is a kind of CP relay.Typical applications include: Power windows, Auto door lock, Power sunroof, Memory seat, Wiper, Defogger,etc.
Parametrics
CP1-12V absolute maximum ratings: (1)Arrangement: 1 Form A; (2)Contact material: Ag alloy (Cadmium free); (3)Nominal switching capacity (resistive load): 20A 14V DC; (4)Nominal operating power: 640 mW; (5)Min. switching capacity (resistive load): 1 1A 14V DC.
Features
CP1-12V features: (1)Compact flat type; (2)High capacity; (3)Simple footprint pattern enables ease of PC board layout; (4)Sealed construction; (5)PC board terminal and Surface mount terminal types available; (6)Model available for wiper load.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 CP1-12V |
Panasonic Electric Works |
General Purpose / Industrial Relays 20A 12VDC 1 FORM C PCB |
Data Sheet |
|
|
||||||||||||
| Image | Part No | Mfg | Description | |
Pricing (USD) |
Quantity | ||||||||||||
|
CP1-12V |
Panasonic Electric Works |
General Purpose / Industrial Relays 20A 12VDC 1 FORM C PCB |
Data Sheet |
|
|
||||||||||||
