61F-G1

61F-G1, compact plug-in level controller, 60 Hz, 3.5 VA, 1 mA, DIP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $79.00~118.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 10 :	118.00 / Piece
10 ~ 20 :	98.00 / Piece
20 ~ 30 :	79.00 / Piece

PartNumber:: 61F-G1

Brand:: Omron Electronics LLC - OMRON | D/C:

Availability:: Supply Ability: 1000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Mr. Jack's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-08-21

From Other Seller

Part Number:61F-G1
US $79.00 - 118.00
Quantity:

piece

Product Summary

The 61F-G1 is a compact plug-in level controller. Applications are (1)None: General-purpose type; (2)L: Long-distance type; (3)H: High-sensitivity type (reverse acting); (4)HY: High-sensitivity type (standard acting); (5)D: Low-sensitivity type; (6)R: Two-wired type.

Parametrics

61F-G1 absolute maximum ratings: (1)Supply voltage: 24, 100, 110, 120, 200, 220, 230 or 240 VAC; 50/60 Hz; (2)Operating voltage range: 85% to 110% of rated voltage; (3)Interelectrode voltage: 24 VAC; (4)Interelectrode current: Approx. 1 mA; (5)Power consumption: Approx. 3.5 VA max.; (6)Interelectrode operate resistance: Approx. 0 to 4 kΩ.

Features

61F-G1 features: (1)Wide range of models: long-distance, high and low-sensitivity, and two-wired types available; (2)24/100/110/120/200/220/230/240 VAC operation possible; (3)Easy installation on DIN track; (4)Low-voltage (AC)electrodes; (5)Red LED operation indicator provided; (6)Conforms to EMC and LVD Directives; (7)UL/CSA approved.
