Product Summary

The E5EZ-R3T is a basic-type digital temperature controller.

Parametrics

E5EZ-R3T absolute maximum ratings: (1)Current input: 4 to 20 mA or 0 to 20 mA; (2)Voltage input: 1 to 5 V, 0 to 5 V, or 0 to 10 V; (3)max. load current: 40 mA; (4)Output voltage: 12 VDC ±15% (PNP); (5)Ambient operating temperature: -10 to 55°C (with no condensation or icing), for 3-year warranty: -10 to 50°C; (6)Storage temperature: -25 to 65°C.

Features

E5EZ-R3T features: (1)A PV/SV-status display function can be set to automatically alternate between displaying the status of the Temperature Controller (auto/manual, RUN/STOP, and alarms)and the PV or SV; (2)Preventive maintenance for relays in the Temperature Controller using a Control Output ON/OFF Counter; (3)Three-level display that simultaneously displays the PV, SV, and MV; (4)One-touch operation with PF Key that can be assigned to auto/ manual, RUN/STOP, or other functions.

Diagrams

E5EZ-R3T pin connection

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
E5EZ-R3T AC100240
E5EZ-R3T AC100240

Omron Industrial

Controllers 1/8DIN 100-240VAC Relay Out 3 Alarm

Data Sheet

0-1: $105.44
1-5: $103.10
5-10: $99.54
10-25: $91.15
E5EZ-R3T AC100-240
E5EZ-R3T AC100-240


MEXLA TC RLY OUT 3 ALM

Data Sheet

0-1: $106.65
