Product Summary
The E5EK-AA202 is an advanced digital controller. And it can be used in (1)Electric furnaces; (2)Thermostats; (3)Food-processing machinery; (4)Drying machinery; (5)Molding equipment; (6)Heating devices; (7)Other applications requiring high-precision temperature control.
Parametrics
E5EK-AA202 absolute maximum ratings: (1)Operating voltage range: 85% to 110% of rated supply voltage; (2)Input Thermocouple: K, J, T, E, L, U, N, R, S, B, W, PLII; (3)Auxiliary output: SPST-NO, 3 A at 250 VAC (resistive load); (4)Control method: ON/OFF or advanced PID control (with auto-tuning); (5)Setting method: Digital setting using front panel keys; (6)Indication method: 7-segment digital display and LEDs; (7)Enclosure ratings: Conforms to IEC IP66 and NEMA4 (Indoor use).
Features
E5EK-AA202 features: (1)Modular structure, one-stock type; (2)High-accuracy: 100 ms sampling (for analog input); (3)Advanced tuning which includes fuzzy self-tuning; (4)Conforms to international EMC and safety standards; (5)IP66/NEMA4 (indoor use) front face; (6)Remote set point; (7)Serial communications (RS-232C, RS-422 and RS-485) and transfer output (4 to 20 mA); (8)Position-proportional control model; (9)Heat/Cool control; (10)AC/DC24V types are also available.
