Product Summary

The E5AN-QQ3BT is a New 96 x 96-mm and 48 x 96-mm Basic Temperature Controller with Enhanced Functions and Performance. It is Improved Indication Accuracy and Preventive Maintenance Function.

Parametrics

E5AN-QQ3BT absolute maximum ratings: (1)Power supply voltage: 100 to 240 VAC, 50/60 Hz; (2)Operating voltage range: 85% to 110% of rated supply voltage; (3)Power consumption: 100 to 240 VAC 10 VA, 24 VAC/VDC 5.5 VA (24 VAC)/4 W (24 VDC); (4)Current input: 4 to 20 mA or 0 to 20 mA; (5)Voltage input: 1 to 5 V, 0 to 5 V, or 0 to 10 V; (6)Input impedance: Current input 150 Ω max., Voltage input 1 MΩ min.; (7)Ambient operating temperature: -10 to 55℃ (with no condensation or icing); (8)Ambient operating humidity: 25% to 85%; (9)Storage temperature: -25 to 65℃.

Features

E5AN-QQ3BT features: (1)Thermocouple input: ±0.3% of PV (previous models: ±0.5%); (2)Pt input: ±0.2% of PV (previous models: ±0.5%); (3)Analog input: ±0.2% FS (previous models: ±0.5%); (4)A PV/SV-status display function can be set to automatically alternate between displaying the status of the Temperature Controller (auto/manual, RUN/STOP, and alarms) and the PV or SV; (5)Preventive maintenance for relays in the Temperature Controller using a Control Output ON/OFF Counter; (6)Three-level display that simultaneously displays the PV, SV, and MV; (7)One-touch operation with PF Key that can be assigned to auto/manual, RUN/STOP, or other functions.

Diagrams

E5AN-QQ3BT package dimensions
