Product Summary

The S8VS-18024A is a switch mode power supply.

Parametrics

S8VS-18024A absolute maximum ratings: (1)Voltage adjustment range: -10% to 15% (with V.ADJ); (2)Input variation influence: 0.5% max. (at 85- to 264-VAC input, 100% load); (3)Load variation influence: 2.0% max. (5 V), 1.5% max. (12 V, 24 V), (with rated input, 0 to 100% load); (4)Temperature variation influence: 0.05%/°C max.; (5)Storage temperature: -25 to 65°C; (6)Operating ambient humidity: 25% to 85% (Storage humidity: 25% to 90%); (7)AInsulation resistance 100 MΩ min. (between all outputs and all inputs/ PE terminals) at 500 VDC; (8)Vibration resistance 10 to 55 Hz, 0.375-mm single amplitude for 2 h each in X, Y, and Z directions.

Features

S8VS-18024A features: (1)New 90-W models with indication monitor that conform to UL Class 2 Output standards; (2)New models with screwless terminal blocks and indication monitor; (3)Status displayed on 3-digit, 7-segment display; (4)Safety standards: UL 508/60950-1, CSA C22.2 No. 107.1/60950-1 EN 50178 (= VDE 0160) EN 60950-1 (= VDE 0805 Teil 1); (5)Input conditions: DC input is also possible from 80 to 370 VDC (Not compliant with EC Directives and other safety standards.); (6)Mount to DIN Rail.

Diagrams

S8VS-18024A dimension figure

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
S8VS-18024A
S8VS-18024A
Omron Industrial
DIN Rail Power Supplies 180W 7.5A 24V Maint forecast
Data Sheet
0-1: $246.70
1-2: $239.22
2-5: $227.26
5-10: $212.32
S8VS-18024A-F
S8VS-18024A-F
Omron Industrial
DIN Rail Power Supplies 120W Sinking , Screw Run Time w/o Alarm
Data Sheet
0-1: $277.66
1-10: $271.48
10-25: $262.12
S8VS-18024AP-F
S8VS-18024AP-F
Omron Industrial
DIN Rail Power Supplies 120W Sink Screwless Run Time w/o Alarm
Data Sheet
0-1: $277.66
1-10: $271.48
10-25: $262.12
S8VS-18024AP
S8VS-18024AP
Omron Industrial
DIN Rail Power Supplies 24V 7.5A 100-240 Lif e Dis Sour
Data Sheet
0-1: $327.04
1-5: $297.32
5-10: $272.55
10-20: $251.59
