Product Summary

The ES-32DC is a Long-distance Separate-amplifier Proximity Sensor.

Parametrics

ES-32DC absolute maximum ratings: (1)Power supply: 10 to 28 VDC; (2)Control output: NPN 200 mA (40 V) max.; (3)Current/power consumption: 18 mA max.; (4)Response time: 1 ms max.; (5)Temperature fluctuation: ±8% of detecting distance at +23℃, within 0 to +50°C; (6)Disconnection alarm output NPN: 100 mA (40 V) max. Residual voltage: 1 V max.; (7)Ambient temperature: 0 to +50℃, No freezing; (8)Relative humidity: 35 to 85%, No condensation; (9)Weight: Approx. 48 g.

Features

ES-32DC features: (1)Detecting distance twice that of conventional sensors; (2)Detecting distance easily adjustable; (3)Wide range of sensor head types available; (4)Built-in alarm output.

Diagrams

ES-32DC block diagram
