Product Summary

The E3X-DA11-S is a super dual fiber sensor.

Parametrics

E3X-DA11-S absolute maximum ratings: (1)Power supply voltage: 12 to 24 VDC ±10%, ripple (p-p)10% max.; (2)Power consumption: 960 mW max. (current consumption: 40 mA max. at power supply voltage of 24 VDC); (3)Control output Load power supply voltage: 26.4 VDC; NPN/PNP open collector;; (4)load current: 50 mA max.; residual voltage: 1 V max.; (5)Insulation resistance: 20 MΩ min. (at 500 VDC); (6)Dielectric strength: 1,000 VAC at 50/60 Hz for 1 minute.

Features

E3X-DA11-S features: (1)Active Threshold Control (ATC)Automatically adjusts the threshold value; (2)ATC Error Output (Selectable Function)Provides an error output when ATC does not adjust the threshold value; (3)Alarm Output (Selectable Function)Provides an alarm when maintenance is required.

Diagrams

E3X-DA11-S pin connection

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
E3X-DA11-S
E3X-DA11-S


RED LED NPN PREWIRE PTUNE

Data Sheet

0-1: $124.15
1-25: $114.95
25-50: $107.29
50-100: $99.63
E3X-DA11-S-6 2M
E3X-DA11-S-6 2M

Omron Industrial

Photoelectric Sensors AMAT

Data Sheet

0-1: $204.92
1-5: $191.44
5-10: $185.37
10-20: $182.00
