Product Summary
The SKIIP613GB123CT is an IGBT module.
Parametrics
SKIIP613GB123CT absolute maximum ratings: (1)VCES: 600V; (2)VCC: 400V; (3)VGES: ±20V; (4)IC: 600A; (5)IF=-IC: 560A; (6)IFSM: 6000A; (7)I2T: 180 kA2s; (8)TJ: -40 to 150℃; (9)Viso: 2500V.
Features
SKIIP613GB123CT features: features: (1)SKIIP technology inside; (2)Low loss IGBTs; (3)CAL diode technology; (4)Integrated current sensor; (5)Integrated temperature sensor; (6)Integrated heat sink; (7)IEC 60721-3-3(humidity) class 3K3/IE32; (8)IEC 68T.1(climate)40/125/56; (9)UL recognized file no.E63 532 (SKIIP 3 power section).
