Product Summary
The CM1200HB-50H is a high power switching use insulated type module. The applications of the CM1200HB-50H include Inverters, Converters, DC choppers, Induction heating, DC to DC converters.
Parametrics
CM1200HB-50H absolute maximum ratings: (1)Collector current, VCES: 2500V; (2)Gate-emitter voltage, VGES: ±20V; (3)Collector current, IC: 1200V; ICM: 2400V; (4)Emitter current, IE: 1200V; IEM: 2400V; (5)Maximum collector dissipation, PC: 15600W; (6)Junction temperature, Tj: -40 to 150℃; (7)Storage temperature, Tstg: -40 to 125℃; (8)Isolation voltage, Visol: 6000V.
Features
CM1200HB-50H features: (1)IC: 1200A; (2)VCES: 2500V; (3)Insulated Type; (4)1-element in a pack.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 CM1200HB-50H |
Other |
|
Data Sheet |
Negotiable |
|
||||
