Product Summary
The 2MBI75P-140 is an IGBT module. The device is suitable for General purpose inverter, AC and DC Servo drive amplifier and Uninterruptible power supply.
Parametrics
2MBI75P-140 absolute maximum ratings: (1)Collector-Emitter voltage, VCES: 1400V; (2)Gate-Emitter voltage, VGES: ±20V; (3)Collector current, IC, contimuous: 100A at Tc=25℃; 75A at Tc=80℃; ICp, 1ms: 200A at Tc=25℃; 150A at Tc=80℃; -IC: 75A; -IC pulse: 150A; (4)Collector Power Dissipation PC: 2500W; (5)Junction temperature, Tj: 150℃; (6)Storage temperature, Tstg: -40 to 125℃; (7)Isolation voltage: 2500VAC.
Features
2MBI75P-140 features: (1)Small temperature dependence of the turn-off switching loss; (2)Easy to connect in parallel; (3)Wide RBSOA (square up to 2 time of rated current) and high short-circuit withstand capability; (4)Low loss and soft-switching (reduction of EMI noise).
Diagrams
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||
---|---|---|---|---|---|---|---|---|---|---|
2MBI75P-140 |
Other |
Data Sheet |
Negotiable |
|
||||||
