Product Summary
The ds4e-ml2-dc12v is a highly sensitive 1500V FCC surge withstanding miniature relay. Applications of the ds4e-ml2-dc12v include: Telecommunication equipment, Office equipment, Computer peripherals, Security equipment and Measuring instrumentation.
Parametrics
ds4e-ml2-dc12v absolute maximum ratings: (1) Max. switching power: 60W, 125VA; (2) Max. switching voltage:220V DC, 250V AC; (3) Max. switching current: 2 A DC, AC; (4) Max. carrying current: 3A DC, AC.
Features
ds4e-ml2-dc12v features: (1) High sensitivity: 200 mW pick-up power, 100 mW pick-up power types available; (2) Latching types available; (3) High switching capacity: 60 W, 125 V A; (4) High breakdown voltage: 1,500 V FCC surge between open contacts 1,000 V AC between open contacts; (5) DIP-1C type can be used with 14 pin IC socket, 2C type can be used with 16 pin IC socket, 4C type can be used with 2 sets of 14 pin IC sockets; (6) Gold-cap silver palladium types available for 2 Form C type; (7) Bifurcated contacts are standard.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 DS4E-ML2-DC12V |
Panasonic Electric Works |
Low Signal Relays - PCB 2A 12VDC 4PDT 2 COIL LATCHING |
Data Sheet |
Negotiable |
|
||||
| Image | Part No | Mfg | Description | |
Pricing (USD) |
Quantity | ||||
|
DS4E-M-DC1.5V |
Panasonic Electric Works |
Low Signal Relays - PCB 4 Form C, 1.5VDC 4 Form C 400mW Type |
Data Sheet |
Negotiable |
|
||||
|
DS4E-M-DC12V |
Panasonic Electric Works |
Low Signal Relays - PCB 2A 12VDC 4PDT NON-LATCHING PCB |
Data Sheet |
Negotiable |
|
||||
|
DS4E-M-DC24V |
Panasonic Electric Works |
Low Signal Relays - PCB 2A 24VDC 4PDT NON-LATCHING PCB |
Data Sheet |
Negotiable |
|
||||
|
DS4E-M-DC3V |
Panasonic Electric Works |
Low Signal Relays - PCB 4 Form C, 3VDC 4 Form C 400mW Type |
Data Sheet |
Negotiable |
|
||||
|
DS4E-M-DC48V |
Panasonic Electric Works |
Low Signal Relays - PCB 2A 48VDC 4PDT NON-LATCHING PCB |
Data Sheet |
Negotiable |
|
||||
|
DS4E-M-DC5V |
Panasonic Electric Works |
Low Signal Relays - PCB 2A 5VDC 4PDT NON-LATCHING PCB |
Data Sheet |
Negotiable |
|
||||
