Product Summary
The V23072-C1061-A308 is a PCB relay, Single relay. Application areas of the V23072-C1061-A308 include Lamp control circuits, Indicator control circuits, Sunroof motors, Window motors, Immobilizers, Central doorlock etc, Also available for 42 V.
Parametrics
V23072-C1061-A308 absolute maximum ratings: (1)Nominal power consumption of the unsuppressed coil at nominal voltage: 1.1 W; (2)Test voltage winding/contact 500: VACrms; (3)Maximum ambient temperature range1): -40 to + 85 °C; (4)Operate time at nominal voltage 2) Typ: -3 ms; (5)Release time at nominal voltage Typ: -1.5 ms.
Features
V23072-C1061-A308 features: (1)60% smaller volume than power relay K; (2)High switching capacity; (3)Small footprint, minimal space requirements.
Diagrams
