Product Summary

The TQ2SA-5V is a low-profile surface-mount relay.

Parametrics

TQ2SA-5V absolute maximum ratings: (1)Nominal voltage: 5 VDC; (2)Pick-up voltage, (max.): 3.75 VDC; (3)Drop-out voltage, (min.): 0.5 VDC; (4)Nominal operating current, (±10%): 28.1 mA; (5)Coil resistance, (±10%): 178 Ω; (6)Nominal operating power: 140 mW; (7)Max. allowable voltage: 7.5 VDC.

Features

TQ2SA-5V features: (1)Low-profile: 6 mm .236 inch in height comforming to EIA standards (Tape height: max. 6.5 mm .256 inch ); (2)Tape and reel package is available as standard packing style; (3)Surge withstand between contacts and coil: 2,500 V; (4)Breakdown voltage between contacts and coil: 1,500 V; (5)High capacity: 2 A; (6)High sensitivity: 2 Form C; 140 mW power consumption (Single side stable type).

Diagrams

TQ2SA-5V pin connection

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
TQ2SA-5V
TQ2SA-5V
Panasonic Electric Works
Low Signal Relays - PCB 2A 5VDC DPDT NON-LATCHING SMD
Data Sheet
0-1: $2.07
1-25: $1.84
25-50: $1.75
50-100: $1.56
TQ2SA-5V-X
TQ2SA-5V-X
Panasonic Electric Works
Low Signal Relays - PCB Low Profile 5V 2Form C 2A 30VDC SMD
Data Sheet
0-500: $1.30
500-1000: $1.26
1000-2500: $1.22
2500-5000: $1.15
TQ2SA-5V-Z
TQ2SA-5V-Z
Panasonic Electric Works
Low Signal Relays - PCB 2 AMP 5VDC DPDT NON-LATCHING
Data Sheet
0-1: $2.07
1-25: $1.84
25-50: $1.75
50-100: $1.66
100-500: $1.56
