Product Summary

The SP2-P-DC12V is one kind of 15A (2 Form C), 10A (4 Form C) compact power relay with high sensitivity.This power relay is often chosen for NC machines and electrical power remote monitoring control panels, and for power supplies used in computers and other equipment. The SP also often provides power control for high-end business and industrial equipment.

Parametrics

SP2-P-DC12V absolute maximum ratings: (1)Arrangement: 2 Form C, 4 Form C; (2)Min. switching capacity (Reference value): 100 mA 5V DC; (3)Max. operating speed: 20 cpm (at rated load); (4)Operate time [Set time]: Max. 30 ms [Max. 30 ms]; (5)Release time [Reset time]: Max. 20 ms [Max. 30 ms].

Features

SP2-P-DC12V features: (1)Miniature size with universal terminal footprint; (2)High sensitivity: 10 A; (3)High reliability and long life; (4)Latching types also available; (5)Strong resistance to vibration and shock.

Diagrams

SP2-P-DC12V dimension figure

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
SP2-P-DC12V
SP2-P-DC12V

Panasonic Electric Works

General Purpose / Industrial Relays 2 Form C 12VDC 15A 250VAC 10A 30VDC

Data Sheet

0-1: $17.41
1-25: $15.94
25-50: $14.24
50-100: $12.10
