Product Summary

The MYAA024D is a kind of 5A Slim Power Relay. It is widely used in PLC, I/O module inverter control.

Parametrics

MYAA024D absolute maximum ratings: (1)Configuration: 1 form A; (2)Construction: Single; (3)Material: Gold overlay silver alloy (Ag90 Ni10+Au); (4)Resistance (initial): Max. 30 mΩ at 6 VDC, 1 A; (5)Contact rating: 5A, 250VAC / 30VDC; (6)Max. carrying current: 5A; (7)Max. switching current: 5A; (8)Max. switching voltage: 277VAC / 125 VDC; (9)Max. switching power: 1,250VA / 150W; (10)Min. switching load: 1 mA, 5 VDC.

Features

MYAA024D features: (1)Width 5mm, height 12mm (31% smaller than NY series); (2)Nominapower: 110mW (8% less than NY series), Operate power: 54mW; (3)High reliable contacts, bifurcated gold overlay silver alloy (cadmium; (4)free); (5)Complies with IEC 61010, 61131; (6)Dielectric strength: 3000VAC; (7)Surge strength: 5080V; (8)Safety standards; (9)UL, CSA, VDE, CQC; (10)RoHS compliant; (11)Plastic sealed type, RTIII.

Diagrams

MYAA024D circuit diagram
