Product Summary

The JW2HN-DC12V is designed as a compact PC board power relay.

Parametrics

JW2HN-DC12V absolute maximum ratings: (1)Arrangement: 1 Form A, 1 Form C and 2 Form A, 2 Form C; (2)Initial contact resistance, max. (By voltage drop 6 V DC 1 A): 100 mΩ; (3)Contact material: Gold-clad silver alloy; (4)Temperature rise: Max. 60°C; (5)Operate time (at nominal voltage): Max. 15 ms; (6)Release time: Approx. 5 ms.

Features

JW2HN-DC12V features: (1)Miniature package with universal terminal footprint; (2)High dielectric withstanding for transient protection: 10,000 V surge in ms between coil and contact; (3)Sealed construction; (4)Class B coil insulation types available; (5)TV rated (TV-5) types available (only for 1 Form A type); (6)VDE, SEMKO, SEV, FIMKO, TV-5 also approved.

Diagrams

JW2HN-DC12V dimension figure
