Product Summary

The H7ET-N1 is a self-powered time counter.

Parametrics

H7ET-N1 absolute maximum ratings: (1)Supply voltage Backlight model: 24 VDC (0.3 W max.); (2)Count input High (logic)level: 4.5 to 30 VDC; (3)Max. counting speed: 30 Hz or 1 KHz; (4)Ambient temperature Operating: -10°C to 55°C, Storage: -25°C to 65°C.

Features

H7ET-N1 features: (1)Seven digits, time range 0 to 3999d23.9h.; (2)Dual time range: 999999.9-3999d23.9h or 999h59m59s-9999h59.9m.

Diagrams

H7ET-N1 pin connection

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
H7ET-N1
H7ET-N1

Omron Industrial

Stopwatches & Timers Time Totalizer LCD

Data Sheet

Negotiable
H7ET-N1-B
H7ET-N1-B

Omron Industrial

Stopwatches & Timers SELF-PWRD TIMER CNTR

Data Sheet

0-1: $45.02
1-5: $44.07
5-10: $43.49
10-25: $42.97
25-50: $35.44
