Product Summary

The H7CN-XLNM is a digital timer.

Parametrics

H7CN-XLNM absolute maximum ratings: (1)Operating voltage range: 85 to 110% of rated voltage; (2)Max. counting speeds (CP1, CP2) 30 cps with contact and solid-state inputs; 5,000 cps with solid-state inputs only; (3)Ambient operating temperature: -10° to 55°C (14° to 131°F); (4)Storage temperature: -25° to 65°C (-13° to 149°F); (5)Ambient operating humidity: 35 to 85% RH; (6)Insulation resistance: 100 mΩ minimum at 500 VDC; (7)Weight: 150 g (5.3 oz.); (8)Input signal Count and reset.

Features

H7CN-XLNM features: (1)Choose from UP, DOWN and reversible counting; (2)Count speed up to 5 K counts per second; (3)Wide-range AC or DC supply voltages; (4)Contact and solid-state output models available; (5)Memory protection circuit available on AC models; (6)Easy-to-read 8 mm-high LED display; (7)Panel mounting adapter, sockets, and accessories available separately.

Diagrams

H7CN-XLNM dimension figure

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
H7CN-XLNM AC100-240
H7CN-XLNM AC100-240
Omron Industrial
Controllers Counter Digital LED
Data Sheet
0-1: $204.83
1-5: $191.36
5-10: $185.29
10-20: $181.93
H7CN-XLNM DC24
H7CN-XLNM DC24
Omron Industrial
Controllers Counter Digital LED
Data Sheet
0-1: $190.71
1-5: $178.16
5-10: $172.52
10-20: $169.39
