The H3DE-H is a Solid-state Power OFF-delay Timer.
Parametrics
H3DE-H absolute maximum ratings: (1)Supply voltage: 24 VAC/DC (50/60 Hz); (2)Operating voltage range: 85% to 110% of rated supply voltage; (3)Power consumption: AC: Approx. 0.3 VA (0.2 W) at 24 VAC, DC: Approx. 0.2 W at 24 VDC; (4)Contact output: 5 A at 250 VAC with resistive load (cosΦ = 1), 5 A at 30 VDC with resistive load (cosΦ = 1); (5)Ambient temperature: Operating –10℃ to 55℃ (with no icing), Storage: –25℃ to 65℃ (with no icing); (6)Ambient humidity Operating: 35% to 85%.
Features
H3DE-H features: (1)Two delay-time models available: 0.1 to 12 seconds (S Series), 1 to 120 seconds (L Series); (2)Covers wide range of supply voltage; (3)Conforms to EMC Standard (EN50081-2 and EN50082-2).
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 H3DE-H AC/DC24 L |
Omron Industrial |
Controllers Timer Din MNT 22.5mm |
Data Sheet |
Negotiable |
|
||||
|
H3DE-H AC/DC24 S |
Omron Industrial |
Controllers TIMER DIN MNT 22.5mm |
Data Sheet |
Negotiable |
|
||||
|
H3DE-H AC100-120 L |
Omron Industrial |
Controllers Timer Din Mnt 2 2.5 mm |
Data Sheet |
Negotiable |
|
||||
|
H3DE-H AC100-120 S |
|
TIMER MULTI ANLG DIN MNT 22.5MM |
Data Sheet |
Negotiable |
|
||||
|
H3DE-H AC200-230 L |
|
TIMER MULTI ANLG DIN MNT 22.5MM |
Data Sheet |
Negotiable |
|
||||
|
H3DE-H AC200-230 S |
|
TIMER MULTI ANLG DIN MNT 22.5MM |
Data Sheet |
Negotiable |
|
||||
|
H3DE-H-AC200230-S |
Omron Industrial |
Controllers SOLID STATE TIMER |
Data Sheet |
Negotiable |
|
||||
|
H3DE-H AC/DC48 S |
Omron Industrial |
Controllers TIMER DIN MNT 22.5mm |
Data Sheet |
Negotiable |
|
||||
