H3AM-NS-B

H3AM-NS-B, mechatronic analog timer, 50/60 Hz, 0.5 s, 5 WVAC

Rated 5 Rating 5 | reviews | Write a review

Price:: US $140.00~211.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 10 :	211.00 / Piece
10 ~ 20 :	176.00 / Piece
20 ~ 30 :	140.00 / Piece

PartNumber:: H3AM-NS-B

Brand:: Omron Electronics LLC - OMRON | D/C:

Availability:: Supply Ability: 1000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Mr. Jack's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-08-16

From Other Seller

Part Number:H3AM-NS-B
US $140.00 - 211.00
H3AM-NS-B

US $130.00 - 200.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The H3AM-NS-B is a mechatronic analog timer.

Parametrics

H3AM-NS-B absolute maximum ratings: (1)Rated supply voltage: 100 to 240 VAC (50/60 Hz); (2)Operating voltage range: 85% to 110% of rated supply voltage; (3)Power reset (-NS) Minimum power-opening time: 0.5 s; (4)Reset input time (-NSR) Minimum input time: 0.5 s; (5)Reset voltage range (-NSR) H level: 85 to 264 VAC; (6)Power consumption: Approx. 9 VA (Approx. 5 W); (7)Ambient humidity Operating: 35% to 85%.

Features

H3AM-NS-B features: (1)Incorporating an easy-to-see large setting dial with moving pointers; (2)Wide time-setting range of 0.2 s to 60 h (available through three time-range model types); (3)Wide AC power supply range (100 to 240 VAC); (4)IP65 watertight and dust-tight front panel; (5)Approved by UL and CSA; (6)Conforms to EN61812-1 and IEC60664-1 4 kV for Low Voltage, and EMC Directives; (7)Conforms to EMC standards; (8)Six-language instruction manual provided; (9)Programmable contact enables the building of a self-holding relay circuit as well as built-in instantaneous contact. (-NS); (10)?Memory retention (-NSR); (11)Finger protection terminal block; (12)Enables easy sequence checks through instantaneous outputs for a zero set value at any time range.
