G32A-A10-VD

G32A-A10-VD, Solid State Relay, 10 A, 19 to 264 VAC, 60 Hz, Omron Electronics LLC

Rated 5 Rating 5 | reviews | Write a review

Price:: US $39.00~59.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 20 :	59.00 / Piece
20 ~ 60 :	49.00 / Piece
60 ~ 80 :	39.00 / Piece

PartNumber:: G32A-A10-VD

Brand:: Omron Electronics LLC - OMRON | D/C:

Availability:: Supply Ability: 1000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Mr. Jack's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-08-15

From Other Seller

Part Number:G32A-A10-VD
US $39.00 - 59.00
Quantity:

piece

Product Summary

The G32A-A10-VD is a Solid State Relay which is the Extremely Thin Relay Integrated with Heat Sinks.

Parametrics

G32A-A10-VD absolute maximum ratings: (1)Carry current: 10 A; (2)Load voltage range: 19 to 264 VAC; (3)Rated Input voltage: 5 to 24 VDC; (4)Operating Voltage range: 4 to 30 VDC; (5)Input current impedance: 7 mA max.; (6)Must operate voltage: 4 VDC max.; (7)Must release voltage: 1 VDC min.; (8)Load current: 0.1 to 10 A; (9)Inrush current: 150 A (60 Hz, 1 cycle).

Features

G32A-A10-VD features: (1)Downsizing achieved through optimum design of heat sink; (2)Mounting possible via screws or via DIN track; (3)Close mounting possible for linking terminals; (4)Applicable with 3-phase loads; (5)Replaceable power element cartridges; (6)Complies with VDE 0160 (finger protection), with a dielectric strength of 4,000 V between input and load; (7)Complies with VDE 0805, IEC 950; (8)Certified by UL, CSA, and VDE (reinforced insulation).
