Product Summary

The F3AA012E is a kind of 3A Slim Type Relay.

Parametrics

F3AA012E absolute maximum ratings: (1)Configuration: 1 form A; (2)Construction: Single; (3)Material: Silver nickel (AgNi); (4)Resistance (Initial): Max. 100 mΩ at 1 A, 6 VDC; (5)Contact rating (resistive): 30VDC, 3A / 125VAC; (6)Max. carrying current: 5A; (7)Max. switching voltage: 277 VAC / 30VDC; (8)Max. switching power: 750VA / 90W; (9)Min. switching load: 10mA, 5VDC.

Features

F3AA012E features: (1)High density mounting; (2)High insulation; (3)Cadmium free contact for eco-program; (4)Safety standards: UL, CSA, VDE, SEMKO, CQC; (5)Plastic sealed relay, RTIII; (6)RoHS compliant.

Diagrams

F3AA012E circuit diagram
