Product Summary

The EB2-4N3 is designed as a miniature signal relay. And it can be used in electronic switching systems, PBX, key telephone systems, automatic test equipment and other electronic equipment.

Parametrics

EB2-4N3 absolute maximum ratings: (1)Contact form: 2 Form c; (2)Contact material: Silver alloy with gold alloy overlay; (3)Minimum contact ratings: 10 mVdc, 10 μA; (4)Initial Contact Resistance: 50 mΩ typ. (Initial); (5)Operate Time (Excluding Bounce): Approx. 2 ms; (6)Release Time (Excluding Bounce): Approx. 1 ms without diode; (7)Insulation Resistance: 1000 MΩ at 500 Vdc.

Features

EB2-4N3 features: (1)Compact and lightweight : 7.5 mm x 14.3 mm x 9.3 mm, 1.5 g; (2)2 form c contact arrangement; (3)Low power consumption; (4)Low magnetic interference; (5)Breakdown voltage: 1 000 VAC (surge voltage 1 500 V), FCC Part 68 conformable; (6)UL recognized (E73266), CSA certified (LR 46266); (7)Lineup in non-latch, single-coil latch and double-coil latch types; (8)Lineup in minimum footprint (9.3 x 14.3), and high solder joint reliability (20 years) types; (9)a Lineup in low profile type (hight: 6.5 mm), and Ultra-low profile (hight: 5.6 mm).

Diagrams

EB2-4N3 dimension figure
