Product Summary

The AGN20012 is a kind of Low Signal Relay.Typical applications include: (1)Telephonic equipment; (2)Telecommunications equipment; (3)Security equipment; (4)Test and Measurement equipment; (5)Electronic Consumer and Audio Visual equipment.

Parametrics

AGN20012 absolute maximum ratings: (1)Contact Form: 2 Form C (DPDT-BM); (2)Contact Current Rating: 1 A; (3)Coil Voltage: 12 VDC; (4)Maximum Switching Current: 1 A; (5)Coil Current: 11.7 mA; (6)Coil Type: Single Side Stable; (7)Power Consumption: 140 mW; (8)Termination Style: Solder Pad; (9)Contact Rating: 1 A at 30 VDC / 300 mA at 125 VAC.

Features

AGN20012 features: (1)Compact slim body saves space; (2)High sensitivity single side stable type (Nominal operating power:; (3)100mW) is available; (4)Outstanding surge resistance; (5)The use of twin crossbar contacts ensures high contact reliability; (6)Increased packaging density; (7)Nominal operating power: 140 mW; (8)Sealed construction allows automatic washing.

Diagrams

AGN20012 circuit diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
AGN20012
AGN20012
Panasonic Electric Works
Low Signal Relays - PCB 1A 12VDC DPDT NON-LATCHING PCB
Data Sheet
0-1: $2.15
1-25: $2.08
25-50: $1.96
50-100: $1.76
