Product Summary

The H5F-B is a Daily Time Control with Simple Operations (Operation Day Selection Possible).

Parametrics

H5F-B absolute maximum ratings: (1)Rated supply voltage: 100 to 240 VAC (50/60 Hz); (2)Operating voltage range: 85% to 110% of rated supply voltage; (3)Power consumption: Approx. 2.4 VA at 264 VAC; (4)Control outputs Contact output: SPST-NO, 15 A at 250 VAC, resistive load, 10 A at 24 VDC, resistive load; (5)Control outputs Minimum applied load: 100 mA at 5 VDC (failure level: P, reference value); (6)Terminal screw tightening torque 0.98 to 1.17 N · m.

Features

H5F-B features: (1)Up to 12 ON/OFF operations (24 for pulse-output operation); (2)Special holidays can be handled easily with the holiday setting function; (3)Adjustments for sudden schedule changes can be made easily using output override and automatic return operation; (4)The operation program can be checked easily with the program check function; (5)Enables pulse output operation and summer time setting; (6)Incorporates finger-safe terminals; (7)Conforms to UL, CSA, and CE marking; (8)Meets a variety of mounting requirements: flush mounting, surface mounting, and DIN track mounting.

Diagrams

H5F-B package dimensions

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
H5F-B
H5F-B

Omron Industrial

Stopwatches & Timers FLUSH MNT DAILY

Data Sheet

0-1: $142.20
1-10: $137.96
10-25: $117.00
25-50: $112.72
Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
H5F-B
H5F-B

Omron Industrial

Stopwatches & Timers FLUSH MNT DAILY

Data Sheet

0-1: $142.20
1-10: $137.96
10-25: $117.00
25-50: $112.72
H5F-FB
H5F-FB

Omron Industrial

Stopwatches & Timers Timer Weekly

Data Sheet

0-1: $137.08
1-5: $134.02
5-10: $129.40
10-25: $124.78
H5F-KB
H5F-KB

Omron Industrial

Stopwatches & Timers TRACK MNT DAILY

Data Sheet

0-1: $148.57
1-10: $138.25
10-25: $129.28
25-50: $121.39
