Product Summary

The KK3000A/1600V is a fast turn-off thyhristor. Typical applications include: (1)Inverter, Chopper, Inductor; (2)Various types of forced converter.

Parametrics

KK3000A/1600V absolute maximum ratings: (1)IT(AV): 3000 A; (2)VDRM/VRRM: 600 to 2500 V; (3)Tq: 40 to 80 us; (4)ITSM: 44 KA.

Features

KK3000A/1600V features: (1)Full diffusion process,capsule type ceramic package; (2)Distributed extension to amplify the gate structure; (3)Excellent dynamic characteristic; (4)Low switching loss, Double-sided cooling; (5)Fast switching performance.

Diagrams

KK3000A/1600V circuit diagram
